virgin uhmwpe outrigger pad :

Key Words

Easy to clean chemical resistance high load capacity Easy to maintenance Oil resistance Durable and Long lasting Waterproof Unbreakable

1. Product Description

Xinxing outrigger pads supply a range of lightweight and long-lasting spreader plates that offer stable support when operating cranes, aerial work platforms and mobile plant. Made from high quality, heavy duty UHMW polyethylene, our range of outrigger pads offer protection against water, corrosion and splintering – a huge advancement over the more traditional wooden and steel alternatives.

Stable support is achieved by spreading the load from the stabiliser or outrigger foot over the large and tough surface of an outrigger pad or crane mat. The overall pressure on the ground is reduced by applying the load over a wider surface area, and effectively supporting the machinery or vehicle. Our range of outrigger pads are durable yet lightweight, making them safe and easy to handle.

Xinxing crane outrigger pads can be used not only as crane leg pads, but also the trailer plates, sleeper of heavy machinery track mats of heavy trucks. The pads are strong and solid designed to support your crane.

Outrigger pads offer a wide variety of products covering most applications, with vertical load bearing capacities from 5 to 70 tonnes and prices to suit all budgets.

2. Application

Crane outrigger pads

Crane foot bearing support

Crane stabilizer pads

Engineered outrigger pad

Heavy duty outrigger pad

Jack outrigger pad

Crane mat

Portable outrigger pad

Uhmwpe outrigger pad

UHMW polyethylene outrigger pad

Crane support pad

Truck foot pads

Mobile crane mats

Thickness (inch)    Pad size (inch)    Part Number    45o Load (ton)    VerticalLoad    Pad Weight

1” Square    18X18    X1T1818    14 tonnes    25 tonnes    5.00kgs

1” Rectangle    20X24    X1T2024    16 tonnes    27 tonnes    7.63kgs

1”Square    24X24    X1T2424    16 tonnes    24 tonnes    9.15kgs

1”Square    30X30    X1T3030    18 tonnes    36 tonnes    14.3kgs

1”Square    36X36    X1T3636    19 tonnes    42 tonnes    20.6kgs

1”Square    48X48    X1T4848    22.5 tonnes    59 tonnes    36.62kgs

1”Round    30”Dia    X1TR30    12 tonnes    28 tonnes    11.23kgs

1”Round    36”Dia    X1TR36    15 tonnes    32 tonnes    11.23kgs

1”Round    48”Dia    X1TR48    18 tonnes    45 tonnes    28.75kgs

Thickness (inch)    Pad size (inch)    Part Number    45o Load (ton)    VerticalLoad    Pad Weight

1-1/2” Square    18X18    X1.5T1818    14 tonnes    25 tonnes    7.73kgs

1-1/2” Square    24X24    X1.5T2024    16 tonnes    27 tonnes    13.73kgs

1-1/2” Square    30X30    X1.5T3030    19 tonnes    37 tonnes    21.46kgs

1-1/2” Square    36X36    X1.5T3636    20 tonnes    43 tonnes    31.00kgs

1-1/2” Square    48X48    X1.5T4848    23 tonnes    59 tonnes    55.00kgs

1-1/2” Round    30”Dia    X1.5TR30    14 tonnes    28 tonnes    16.85kgs

1-1/2” Round    36”Dia    X1.5TR36    15 tonnes    32 tonnes    24.24kgs

1-1/2” Round    48”Dia    X1.5TR48    18 tonnes    45 tonnes    43.13kgs

Thickness (inch)    Pad size (inch)    Part Number    45o Load (ton)    VerticalLoad    Pad Weight

2”Square    18X18    X2T1818    14 tonnes    26 tonnes    10.30kgs

2”Rectangle    20X24    X2T2024    18 tonnes    28 tonnes    15.26kgs

2”Square    24X24    X2T2424    18 tonnes    28 tonnes    18.31kgs

2”Square    30X30    X2T3030    19.5 tonnes    38tonnes    28.62kgs

2”Square    36X36    X2T3636    20 tonnes    44 tonnes    41.20kgs

2”Square    48X48    X2T4848    25 tonnes    63 tonnes    73.25kgs

2”Round    30”Dia    X2TR30    15 tonnes    30 tonnes    22.47kgs

2”Round    36”Dia    X2TR36    16 tonnes    32 tonnes    32.33kgs

2”Round    48”Dia    X2TR48    19 tonnes    45 tonnes    57.51kgs

Thickness (inch)    Pad size (inch)    Part Number    45o Load (ton)    VerticalLoad    Pad Weight

2 -1/2” Square    24X24    X2.5T2424    17.5 tonnes    28 tonnes    22.89kgs

2 -1/2” Square    30X30    X2.5T3030    19 tonnes    39 tonnes    35.76kgs

2 -1/2” Square    36X36    X2.5T3636    20 tonnes    45 tonnes    51.50kgs

2 -1/2” Square    48X48    X2.5T4848    24 tonnes    60 tonnes    91.56kgs

2 -1/2” Round    30”Dia    X2.5TR30    15 tonnes    29 tonnes    28.09kgs

2 -1/2” Round    36”Dia    X2.5TR36    15.3 tonnes    33 tonnes    40.41kgs

2 -1/2” Round    48”Dia    X2.5TR48    19 tonnes    46 tonnes    71.88kgs

Thickness (inch)    Pad size (inch)    Part Number    45o Load (ton)    VerticalLoad    Pad Weight

3”Square    24X24    X3T2424    18 tonnes    29 tonnes    27.47kgs

3”Square    30X30    X3T3030    20 tonnes    40 tonnes    42.92kgs

3”Square    36X36    X3T3636    22 tonnes    47 tonnes    61.80kgs

3”Square    48X48    X3T4848    26 tonnes    66 tonnes    109.87kgs

3”Round    30”Dia    X3TR30    15 tonnes    30 tonnes    33.70 kgs

3”Round    36”Dia    X3TR36    16 tonnes    36 tonnes    48.49kgs

3”Round    48”Dia    X3TR48    20 tonnes    51 tonnes    86.26kgs

LOADING CONTAINER: The loading quantity will be calculated according to the actual situation.

black and yellow are our main color

green, red, orange, white, grey
