Customized Shape Composite Material Support Boards Base Plate Road Protection Mat Crane Outrigger Pad :

UHMWPE jacking block


uhmwpe jack block


UHMWPE outrigger pad


UHMWPE stabilizer pad


UHMW-PE rigger pad


Description

Customized Shape Composite Material Support Boards Base Plate Road Protection Mat Crane Outrigger PadCustomized Shape Composite Material Support Boards Base Plate Road Protection Mat Crane Outrigger Pad


Portable and rigid UHMWPE plastic outrigger pads/jack pads/cribbing plate for crane truck

The outrigger pad is mainly used for cushion under the outrigger of the construction machinery, and plays the supporting role.This material has higher strength and stiffness, and then can reduce the deformation of the pad body, and provide more stable supporting force for construction machinery. Water zero absorption, corrosion resistance, this material will not split or corrosion can replace the more traditional wood and steel substitutes, greatly saving the cost of use and improve the quality of work.

Four-corner support of outrigger pad can be used under harsh environment, but not broken. The hand-held rope is made of nylon material, and the end of the hand-held rope is embedded in the base plate body for convenient transportation and arrangement. The process composite uhmwpe leg pad is processed by numerical control machine in the later stage of press molding.


Advantage

1.Very flat on the surface.

2.The thickness tolerance is 2 -0,some made according to your requirements.
3.The color is pure and any color can be made by us.
4.We can give you an accurate size of UHMW-PE Sheet with advanced machine.
5.Different shaped UHMW-PE Sheets also can be made by us like bending sheet.
6.According to different requirements with different application special specifications can be customized, like anti-UV,fire-resistant,anti-static and with other characters.



Size

Thinckness
Size
Load Capacity(TONS)
Weight
MM
MM
45°
Vertical
KGS





25MM
500*500
30
55
6.25
600*600
35
60
9
800*800
40
81
16
1000*1000
43
93
25
1200*1200
50
130
36
Dia.800
38
78
12.5
Dia.1000
41
91
20
Dia.1200
48
110
28





40mm
500*500
31
56
10
600*600
36
61
14.4
800*800
42
82
25.6
1000*1000
44
94
40
1200*1200
51
131
57.6
Dia.800
40
80
20
Dia.1000
42
92
32
Dia.1200
48
130
45





50mm
500*500
31
58
12.5
600*600
40
62
18
800*800
43
85
32
1000*1000
45
98
50
1200*1200
55
140
72
Dia.800
41
83
25
Dia.1000
43
95
40
Dia.1200
52
137
56



60mm
800*800
43
86
38.4
1000*1000
45
99
60
1000*1000
53
133
86.4
Dia.800
41
84
30
Dia.1000
42
96
48


Color

black,yellow,green, red, white, orange, grey, blue

Applications

uhmw cribbing block


Applications

・Logging equipment
・Mining equipment
・Concrete protection liner
・Oil and gas equipment
・Wind energy equipment
・Boom trucks
・Tow trucks
・Construction equipment
・Mobile cranes
・Aerial lifts
・Digger derricks
・Concrete pumpers
・Fire trucks
・Utility trucks
・Military vehicles
