4x8 ft High quality recycled engineering plastic polyethylene UHMWPE sheets :

UHMWPE sheet is used for conveyor guide rails, belt scrapers, chain guides, bearings, sprockets, rollers and wear plates. UHMWPE areas of applications also include chemical tanks, mining processing equipment, bulk material handling, transportation and recreation equipment.

Ultra high molecular weight polyethylene is known as UHMWPE for short or PE1000 due to its molecular weight. UHMWPE has outstanding abrasion resistance, non sticking, excellent mechanical properties and superior impact strength, even at temperatures below -200°C. These excellent properties means UHMWPE is used for food and beverage machinery, bulk material handling, chemical and mining processing equipment and much more. UHMWPE can be machined into vitually anything from gears, bearings to large sprockets. This PE1000 grade plastic can even outperform steel in sliding applications because of its low coefficient of friction.

Inquire Now Next Product

Description

Wear Resistance UHMWPE Sheet, molecular weight 9.2 million g/mol, offers a higher wear resistance and impact strength compared to PE300 and PE500. It is extremely strong with excellent wear resistance due to a very low coefficient of friction. It also has excellent chemical resistance and very low moisture absorption. Polyethylene PE1000 sheet - UHMW is food grade approved.

Characteristic of UHMWPE Sheets:

1.Very flat on the surface

2.The thickness tolerance is +2 -0,some made according to your requirements.

3.The color is pure and any color can be made by us.

4.We can give you an accurate size of UHMWPE plate with advanced machine.

5.Different shaped UHMWPE plate also can be made by us like bending sheet.

6.According to different requirements with different application, special specifications can be customized, like anti-UV, fire-resistant, anti-static and with other characters.

Key Features and Advantages of UHMWPE Sheets：

--Highest abrasion resistance of any polymer, 6 times more wear resistant than steel

--Anti-Weather & Anti-Aging

--Self-lubricating, Very low coefficient of friction

--Excellent chemical & corrosion resistant

--superior impact resistant, Noise- absorption, Vibration-absorption

--Temperature range: -2600C ~ +800C; Very high resistance to cold,doesn't become fragile even under -1800C

--High tensile Strength

--Non-Toxic and smell

--UV resistance

--Flame Retardant; Relatively low in water absorption

--Excellent electrical properties

--Good performance in resisting environment stress crack, 200 times of ordinary PE

--No adhesion

--Light weight and easier to handle and fix

--Cost efficient; Resulting in low energy consumption

--Does not rot, split or crack; 100% recyclable

--Great liner material for industrial material handling applications--Easy Reprocessed

Size

2000x1000x(6-300)mm		3050x3050x(6-300)mm
5040x1330x(6-300)mm		4730x1230x(6-300)mm
3050x1220x(6-300)mm		6050x1820x(6-300)mm
3030x1550x(6-300)mm		4520x2000x(6-300)mm
Any size within the standard size is available.

Color

Normal Virgin UHMWPE 1000 Sheet Color:

Black, Blue, Yellow, Green, White, Red, Orange, any other color will be available.

Applications

UHMWPE is used in applications requiring high abrasion resistance and non-stick qualities.

Mining Liners for:

Conveyors, Truck beds, Dragline buckets, Shovels, Front loading buckets, Scrapers, Excavator buckets

Coal Preparation Liners for:

Chutes, Hoppers, Bunkers, Launderer parts, Conveyor skirting, Conveyor troughs, Coal and Ore

Transportation:

Dump truck lining, Ship Hold Liners, Rail car liners, Conveyor liners

Bulk Material Handling:

Grain, Coal, Sand, Gravel, Urea Phosphates, Wood Chips, Kaolin Powder, Soap Powder, Dry Fertilizer,Foundry Sand, Soda Ash, Gypsum Barite, Dry Cement, Chemical Powder, Fly Ash & Bottom Ash
