UHMWPE/HDPE pad hockey shooting pad ice rink boards :

Hockey Shooting Pads provide the ideal surface for training or practising shooting skills, stick handling and goaltending! Our hockey shooting board/shooting pad/shooting mat is has been specifically engineered to replicate an ice hockey surface.


Use the hockey shooting board to practice your wrist shot and snap shot, or even your slap shot in a confinedspace. Any drill that involves stationary shooting can be done with this hockey shooting mat, as well as stationary stickhandling drills.


The material used to make the shooting pads is HDPE or High-density polyethylene. This material is known to be very durable (lasting over 100 years in some cases) and also be very slippery. HDPE is used in snowboarding and skiing to construct boxes and rails, and also in the boards that are used in hockey arenas.


Description

  • Our Xinxing hockey shooting board is has been specifically engineered to replicate an ice hockey surface.

  • Use the hockey shooting board to practice your wrist shot and snap shot, or even your slap shot in a confined space. Any drill that involves stationary shooting can be done with this hockey shooting mat, as well as stationary stickhandling drills.
  • Simulate real on ice puck action
  •  Great surface for any hockey player to practice and increase his or her stick handling and shooting skills
  •  Slippery, smooth yet protects those very expensive hockey sticks from rough surfaces
  •  Maximize your off ice shooting and stick handling practicing, anywhere any time
  • Easy to carry around and store with our machined in handle slots


Advantages of this product:

●  Excellent wear resistance;
●  Self-lubricating;
●  Excellent abrasion Resistance;
●  Blunt impact resistance;
●  Corrosion and chemical resistance;
●  Low-temperature resistance;
●  Excellent mechanical properties;
●  Hygienic and non-poisonous;
●  Excellent mechanical properties;

●   Low maintenance cost


Puckboard is also known as “HDPE” or “High Density Poly Ethylene"

Makes off-ice hockey shooting practice fun.

Simulates real on ice puck action.

Slippery, smooth yet protects those very expensive hockey sticks from rough surfaces.

Great surface for any hockey player to practice and increase his or her stick handling and shooting skills.

Maximize your off ice shooting and stick handling practicing, anywhere any time!

Easy to carry around and store with our machined in handle slots.

In stock and ready to ship.

Superior plastic for impact resistance, easy to cut at home, and flexible in varying degrees, within certain thicknesses.The same material used in hockey arenas around the bottom portion of the rink where pucks and skates are more likely to hit.

It is suggested that there are NO glues or paints on the market that will adhere to HDPE, which makes it ideal uses where slippery surfaces are needed such as concrete forming.




Size

Size:  ColorWeight
30"X60"X3/16" (760mmx1520mmx5mm)White5.5kg
28"X52"X3/16" (710mmx1320mmx5mm) White4.5kg
24"X48"X1/8"   (610mmx1220mmx3mm) White2.1kg
30"X60"X1/8"   (760mmx1520mmx3mm)  White3.3kg
48"X96"X1/8"   (1220mmx2440mmx3mm) White8.5kg
58"x24"x1/4"   (1470mmx610mmx6mm) White5.0kg
58"x24"x2/5"   (1470mmx610mmx10mm)  White8.5kg
Other customer size is available with requirements


Color

White, blue, black or as you need

Applications

Use it to practice shooting, passing and stickhandling.

Protect your sticks from rough pavement and concrete.

Bevelled edges make it easier to get pucks onto the mat.

No more tape marks on your floor or driveway.

UV protection makes it excellent for summer training.

Handle makes it easy to carry.


1, sports venues: the rink, basketball court, tennis court, five-a-side football, volleyball, football, hand court, badminton court, table tennis field, skating rink, hockey, goal kick, etc.;

2, parks and leisure facilities, park road, a pavilion floor, villa courtyard;

3, ships: used for ship deck;

4, garden, balcony, villa courtyard;

5, other places: supermarket, basement, parking floor, door mat.



Data Sheet

Physical Properties

Test Method

Unit

Value

Specific Gravity

ASTM D792

g/cm3

0.93

Water Absorption

ASTM D570

<0.01

Mechanical Properties

Test Method

Unit

Value

Tensile Strength

ASTM D638

MPa

40

Elongation, at break

ASTM D638

%

300

Flexural Strength

ASTM D790

MPa

24

Compression Strength, 10% Deformation

ASTM D695

MPa

21

Hardness, Shore D

ASTM D2240

-

D66

Coefficient of Friction

-

-

0.12

Thermal Properties

Test Method

Unit

Value

Heat Deflection Temperature

ASTM D648

47

Melting Point

ASTM D3412

135

Continuous Service Temperature

-

82

Electrical Properties

Test Method

Unit

Value

Surface Resistivity

ASTM D257

Ω-M

>1015

Dielectric Constant 106Hz

ASTM D150


2.3
