PE1000 / PE-UHMW sheets Flame Retardant :

Xinxing Flame-retardant AST UHMWPE Product Description:

Xinxing Flame-retardant AST UHMWPE Product is the first flame retardant and anti static UHMWPE Sheet that has the following specialties:

Halogen free

Antimony free

No strong smoke emission

Non-toxic smokes/gases

Technical properties of UHMWPE are not reduced

Key Features and Benefits:

Impact strength - it is virtually unbreakable

Light weight - easy to handle without special equipment

Electrical insulation - it is a good insulator

Weatherproof - it doesn't absorb water

Chemical resistance - resists corrosive chemicals (Sulphuric Acid, Caustic Soda)

Abrasion resistance - rated better than carbon steel for sliding abrasion applications

Low coefficient of friction - it does not require lubrication

Fire rating - achieved UL94 class V0

UL94HB , UL94-V0 , UL94-V1 , UL94-V2

Xinxing Flame-retardant AST UHMWPE Product AST Applications:

Underground mining

Scraper blades

Hopper liners

Liner beds

Wear profiles

Impact slider bars

Chain guides

Inquire Now Next Product

Description

Flame Retardant UHMWPE Sheet has following advantages:

High flame retardant property

Imported flame retardants imported from Europe

Durable for more than 10 years

Be in the forefront of quality

Flame Retardant UHMWPE Sheet manufacturer, with import and export rights. In the past 11 years, we have been making high-quality Flame Retardant UHMWPE Sheet and constantly innovating and improving our products. Our Flame Retardant UHMWPE Sheet adopts brand-new UHMWPE resin and imported environmental friendly flame retardant. The flame retardant grade of the product fully meets the ul94-2015 standard. The impact resistance and wear resistance of Flame Retardant UHMWPE Sheet are significantly improved compared with the traditional process.

PARFORMANCE

Flame Retardant UHMWPE Sheet is a kind of engineering plastics with superior comprehensive performance, which can be modified to produce flame retardant, antistatic, radiation and other special purpose boards. It has the following comprehensive performance characteristics:

1) Ultra high wear resistance

2) Superior impact resistance

3) Good non stick

4) Good corrosion resistance

TECHNICAL SPECIFICATION

Serial number	project	Company	test method	index
1	Vertical combustion	s	UL94-2015	≤60
2	Oxygen index		GB2406-SO	≥22
3	Horizontal combustion	mm/min	UL94-2015	≤40
4	Molecular weight (viscosity method)	×10	Reference GB1841—80ASTMD4020—81	200—900
5	impact strength	KJ/㎡	GB/T1043.1—2008	≥130
6	bending strength	Mpa	GB/T9341—2008	≥30
7	compressive strength	Mpa	GB/T1041—2008	≥35
8	ball indentation hardness	N/mm²	GB/T3398.1—2008	≥40
9	density	g/cm³	GB/T1033.1—2008	0.96—1
10	friction coefficient		GB/T3960—1983	0.11—0.19
11	Water absorption	％	GB/T1034—2008	≤0.01

APPLICATION

This product is widely used in the following industries

(1) in metallurgy,power, coal, shipbuilding, meat and other industries, the use of Flame Retardant UHMWPE Sheet impact resistance, wear resistance, non-adhesion and self-lubrication.

(2)in the paper industry, the use of Flame Retardant UHMWPE Sheet wear resistance.

(3) in the textile industry, the use of Flame Retardant UHMWPE Sheet impact resistance and wear resistance.

(4) in the machinery industry, the use of Flame Retardant UHMWPE Sheet wear resistance, impact resistance and self-lubrication

Size

3000x1500mm

3000x1200mm

4500x2000mm

6000x1800mm

3000x3000mm

Color

Black
